Ultra Fitration

Parameters

Inlet Feed Concentrations to UF

Outlet / Permeate Concentrations

Total Suspended solids(TSS), mg/l

<30

Below detectable limits

Turbidity, NTU

<15

<1

Silt Density Index, SDI

<25

<1

Oil and Grease, mg/l

<5

<1

Other Operating parameters

70

Maximum continuous chlorine, mg/L

200

Maximum air pressure during integrity test, MPa (bar)

0.2 (2)

Maximum feed water pressure, MPa (bar)

0.6 (6)

Recommended service Trans Membrane pressure , MPa(bar)

< 0.2 (2)

Maximum backwash Trans Membrane pressure, MPa(bar)

<0.15 (1.5)

Working temperature( degree Celsius)

2-40

Operating Philosophy

Cross ow

Model No.

Feed ow

Permeate

GW

SW

WW

GW

SW

WW

AQT UF 0401

0.40

0.32

0.24

0.40

0.3

0.20

AQT UF 0402

0.80

0.65

0.47

0.80

0.6

0.40

AQT UF 0403

1.30

0.97

0.71

1.20

0.9

0.60

AQT UF 0404

1.70

1.29

0.94

1.60

1.20

0.80

AQT UF 0801

2.10

1.61

1.18

2

1.50

1

AQT UF 0802

4.2

3.23

2.35

4

3

2

AQT UF 0803

6.30

4.84

3.53

6

4.50

3

AQT UF 0804

8.4

6.45

4.71

8

6

4

AQT UF 0806

12.60

9.68

7.06

12

9

6

AQT UF 0808

16.8

12.90

9.41

16

12

8

AQT UF 1006

23.2

17.81

12.99

22.08

16.56

11.04

AQT UF 1008

31

23.74

17.32

29.44

22.08

14.72

AQT UF 1010

38.7

29.68

21.65

36.8

27.60

18.40

AQT UF 1012

46.5

35.61

25.98

44.16

33.12

22.08

AQT UF 1014

41.55

30.31

38.64

25.76

AQT UF 1016

47.48

34.64

44.16

29.44

AQT UF 1020

43.29

36.8
